Vacuum Lifting Accessories
Vacuum Lifter Parking Stands

Parking Stands
In the “Down” position, which is recommended when you store the vacuum lifter, the parking stands provide support for the lifter so that the vacuum’s rubber seals will not touch the ground. This protects the seals from damage as well as helping to maintain their shape and prevent them from flattening out.



Two Styles of Parking Stands Available: Standard Spring-Loaded and Pin-Release Styles

  • Spring-Loaded
    Adjustable in Four Positions: Pull Sideways, Turn, Let Go and it Locks in Position
    Spring-Loaded Locking Mechanism Snaps into Position for One-sided, Quick Adjustments
    ANVER Spring-Loaded, Adjustable, Four Position Parking Stands keep the vacuum sealing rings clean and debris-free. PLUS, in their other positions, they can be used to locate the lifter precisely over the load. They feature rugged steel construction.

  • Pin-Release
    Parking Stands available for custom or larger lifters where standard spring-loaded parking stands can not be used.
rfq Part Number Description For Use With

PS-150-3X3 PS-150 (Series)
Bolt-On, 3″ SQ. Beams
M100M, M150M and other Air and Electric vacuum lifters up to 2000 lb (909 kg) capacity and up to 190 inch (7.5 m) beam length.

PS-150-3X6 PS-150 (Series)
Bolt-On, 3″ x 6″ Beams
M100M, M150M and other Air and Electric vacuum lifters up to 2000 lb (909 kg) capacity and up to 190 inch (7.5 m) beam length.

72000173 PS-150 (Series)
Bolt-On, Generator Mounted
M70S, M75S, M100M, VPFL4 & VPF-57 Generators with Pad Attachments

72000174 PS-150 (Series)
Bolt-On, Generator Mounted, Offset
M150S, M150M & M250M Generators with Pad Attachments

72000038 PS-250 (Series)
Bolt-On, 3″ x 6″ Beams
M250M, Air and Electric vacuum lifters over 2000 lb (909 kg), and up to 4600 lb (2090 kg) capacity and typically up to 190 inch (4.8 m) beam length.

72000040 PS-250 (Series)
Adjustable Slide, 3″ x 6″ Beams
M250M, Air and Electric vacuum lifters over 2000 lb (909 kg), and up to 4600 lb (2090 kg) capacity and typically up to 190 inch (4.8 m) beam length.

72000041 PS-250 (Series)
Adjustable Slide, 5″ x 7″ Beams
M250M, Air and Electric vacuum lifters over 2000 lb (909 kg), and up to 4600 lb (2090 kg) capacity and typically up to 190 inch (4.8 m) beam length.

72000127 PS-250 (Series)
Bolt-On, Offset-Mount, 3″ x 6″ Beams
M250M, Air and Electric vacuum lifters over 2000 lb (909 kg), and up to 4600 lb (2090 kg) capacity and typically up to 190 inch (4.8 m) beam length.

72000128 PS-250 (Series)
Bolt-On, 5″ x 7″ Beams
M250M, Air and Electric vacuum lifters over 2000 lb (909 kg), and up to 4600 lb (2090 kg) capacity and typically up to 190 inch (4.8 m) beam length.

Note: For capacities greater than 4600 lb (2090 kg) or beam lengths longer than 110 inch (4.3 m), please contact factory.

Standard Spring-Loaded Parking Stands – Click to Enlarge
PS-150_Down Folded-Down PS-150_Out Folded-Out PS-150_Up Folded-Up PS-150_In Folded-In

Note: In a “Folded In, Out or Up” position, standard spring loaded parking stands provide a Grab Bar for positioning the lifter easily and precisely onto the load from the side of the lifter.

Custom Pin-Release Parking Stands – Click to Enlarge
  ANVER Custom Built Parking Stands for Special Applications



13600004 A
